BACKUP BATTERY SYSTEM-OFF-BOARD

High winds, ice, equipment breakdown, whatever the cause of the electrical outage, don't get stuck using an emergency system.

This backup system allows you to connect your electronic devices to an inverter and take advantage of your battery reserves.

The system makes it possible to power:

-One or more televisions
- The WIFI
-Hotplate, burner, stove
-A microwave
-A 110V fridge
- A 110V freezer
- A 110V washer
-Phone chargers
-A radio
- Water pump
-And more!


Storage capacity: 3,840W
Inverter capacity: 2000W

Connected to the network: No
Automatic relay takeover in the event of a power failure:

Yes, if plugged into an outlet permanently and the desired devices are already connected to it.

For the relay to be taken over automatically, the inverter must be permanently connected to an outlet and the equipment that it must support in the event of a breakdown must be permanently connected to the inverter. When outage, the inverter will seek its power from the batteries.

Otherwise, you will have to turn on your inverter and plug in the devices you want to turn on and/or recharge. The batteries must have been charged beforehand.

Batteries included:

Batterie au lithium Phospha LifePo4 12V 300Ah de DriveMotion

Inverter included:

The KISAE inverter/charger is a 3 in 1 accessory which allows, among other things:

- Transform the battery current into 120V.
- Recharge the system batteries using a generator in the event of prolonged gray weather.

Features:

Inverter:

Inverter type: Pure sine.

Transforms the current into 120V.

Suitable for 12V systems.

Continuous output power at 25°C:
2000W
Peak Power (Max): 4000W

Automatic transfer switch: Yes

The device has:
1 input and 3 outputs 120V (AC).
1 prise 120V
1 prise USB

Charger:

Ampere/Hour: 55

*The device could be connected to a generator in the event of a prolonged outage in order to recharge the batteries.

Protection system included:

MRBF Terminal Fuse Block 30-300A BS5191
Fusible 300A Blue Sea

Cables and connectors included:

1 120 Leviton socket

All the cables needed to connect the devices to each other. The maximum distance between the battery and the inverter is 5 feet.

Solar panels not included:

This backup system does not include solar panel(s) for recharging.

To see other backup system options, see Emergency systems (backup) and Hybrid solar systems of the section of kits on network.

Supports and Fixings not included:

Please visit our Brackets and Fixings section so you can choose the items that match your installation and needs.

Connection diagram and technical support included:

All our emergency (backup) kits come with a connection plan to help you install your equipment.

Although the system does not require any modification to the home's electrical system, we still recommend calling on our installation team or a certified electrician.

Connection to an auxiliary power source:

The assembly includes an inverter which can also act as a charger, when paired with an auxiliary energy source such as a generator.

Still questions?

Our technical support team is here! Take advantage of a direct line when purchasing a kit.

Technical advice:

The components of our solar systems are compatible together. However, the sets are presented to you for information purposes only, we cannot guarantee that they meet your energy needs. It is your responsibility to ensure the sufficiency of the solar systems you purchase. You can contact our advisors for additional information.

*The average sunshine time represents that of Quebec City. The calculation was made by considering in particular the following variables: south orientation, angle of inclination equal to the latitude and no shading. The actual sunshine time depends in particular on the location, orientation, temperature, shading and other parameters specific to your installation. Solar system proposals and plans are for illustrative purposes only. Each installation has its particularities and it is your responsibility to ensure in particular the conformity and sufficiency of your installation.

It is also your responsibility to ensure that the installation is carried out by someone with the necessary skills. By purchasing a solar system, you release us from any liability or damage, on any grounds whatsoever, directly or indirectly linked in particular to the quality or conformity of your installation. Please ensure that the cable lengths and connectors are sufficient for the installation you plan to make. Additionally, because your solar system equipment produces electricity, make sure you know the precautions to take when handling it. Improper installation can damage the components of your system or cause damage to neighboring installations or other property that may be located there. Under no circumstances will we be held liable for such damage.
